BDCOM ALL SHOW COMMAND FOR EPON OLT



BDCOM OLT All Show Command, এটা আপনাকে আশা করছি অনেক সাহায্য করবে। অনেক সময় এমন হয় যে আপনার কোন একটা কমান্ডটা মনে নেই বা ভুলে গেছেন। তো আপনার যদি নোট করা থাকে তাহলে আপনি একটু দেখে নিলেই আপনার কমান্ডটা মনে পরে যাবে।

1. show epon active-onu – All Active ONU information
2. show epon active-onu interface epoN 0/1 – Specific active onu information
3. show epon active-onu mac-address 8479.73fb.3f9d – Search onu by mac address
4. show epon always-laser-on-onu – For check Always laser status on the ONU
5. show epon always-laser-on-onu interface epON 0/1 – For Specific epon Always laser status on the ONU
6. show epon basic-info – Basic information of the OLT
7. show epon encryption – Show Global-level encryption parameters of an OLT
8. show epon encryption interface epoN 0/1 –  Show specific epon interface Global-level encryption parameters of an OLT
9. show epon inactive-onu -For show Inactive ONU information
10. show epon inactive-onu interface epoN 0/1 – For Specific epon interface inactive ONU information
11. show epon interface epON 0/1:6 onu ctc basic-info -For find out ONU mac address
12. show epon interface epON 0/1:1 onu port 1 state – For onu lan port status check
13. show epon interface epon 0/1:14 onu ctc dba – For Show the oNU queue the DBA set the config
14. show aaa users – For Show AAA Active Login user information
15. show aggregator-group detail -For show Link Aggregation(Bonding) information
16. show alias – For show the Alias command
17. show the arp – For show ARP table with ip & interfaces
18. show break – For show  Switch breakpoint information
19. show running-config – For Show full configuration
20. show running-config interface epON 0/1 – For show specific epon interface configuration
21. show running-config interface epON 0/1:4 – For show specific onu configuration
22. show cpu -For how much CPU usage in olt
23. show debug – For show State of each debugging option
24. show dot1x – For show IEEE 802.1X information
25. show epon optical-transceiver-diagnosis – For show all Epon optical power(dBm)
26. show epon optical-transceiver-diagnosis interface epoN 0/1 – For see specific epon all onu optical power(dBm)
27. show epon optical-transceiver-diagnosis interface epON 0/1:4 – For Show Specific ONU optical power(dBm)
28. show gpon onu-optical-transceiver-diagnosis interface gpON 0/7   – For show all onu rx tx power “GPON only”
29. show epon onu-ctc-optical-transceiver-diagnosis interface epoN 0/1 – For show all onu rx tx power
30. show epon onu interface epon 0/x:x onu ctc optical-transiver- diagnosis – For show all onu rx tx power
31. show epon  interface epoN 0/1:2 onu ctc snmp-info – For show ONU SNMP information
32. show epon interface epON 0/1:2 onu d-info – For show Double mac address information
33. show epon interface epON 0/1:2 onu mac address-table – For Show ONU MAC address table
34. show epon interface epon 0/1: 1 onu mac-aging-time -For show onu Mac aging time
35. show epon interface epon 0/1: 1 onu olt-info -For show olt information
36. show epon interface epon 0/1: 1 onu pon-port statistics – For Show ONU interface statistics
37. show epon interface epon 0/1: 1 onu pon-port state – For Show ONU interface state
38. show epon interface epoN 0/2:8 onu port 1 ctc auto-negotiation – For show ONU interface auto negotiation
39. show epon interface epoN 0/2:8 onu port 1 ctc flow-control – For Show ONU interface flow control state
40. show epon interface epon 0/1: 1 onu port 1-4 ctc mcst mc-vlan – For show onu Multicast
41. show epon interface epoN 0/2:8 onu port 1 ctc mcst tag-stripe – For show onu strive vlan tag
42. show epon interface epoN 0/2:8 onu port 1 ctc qos – For show ONU interface qos
43. show epon interface epON 0/1:21 onu port 1 ctc ratelimit-ingress /  egress- Show ONU interface bandwidth limitation
44. show epon loid-bind-table – For show bind LOID The table
45. show arp – For show ARP table here you see olt vlan ip with mac address
46. show configuration – For Show configuration (this option only read mode user)
47. show epon mpcp-registration-mode – For show Multipoint control protocol registration mode
48. show epon onu-authen-method – For need to see onu authentication method
49. show epon onu-information – For see all onu information under every epon
50. show ether-ring – For show display EAPS information(Ethernet Automatic Protection Switching)
51. show interface brief -For show all interface status
52. show interface range epoN 0/1 – For show epon tx & rx power(dBm) & all status
53. show interface Epon 0/1 – For show specific interface information
54. show ip route detail – For show all route in olt
55. show ip route static – For show static route
56. show ip route all – For show routing table
57. show ip route information – For show routing information
58. show ip interface vlAN 1 – For show specific interface ip configuration
59. show local-users -For Show all user
60. show logging – For Show all log
61. show mac-address table – For show all MAC address table
62. show mac address-table interface epoN 0/1 – For show specific epon interface mac table
63. show mac address-table interface epoN 0/1:1 – For show specific onu interface mac table
64. show ip sshd – For show Sshd status
65. show ip traffic – For show ip traffic information
66. Show line – For show line information
67. show running- config – For show olt running configuration
68. show onu-config-template – For show  template-config
69. show policy-map – Show policy-map based bandwidth configuration
70. show telnet – For show incoming telnet connections
71. show vlan – For show Vlan information
72. show mac address-table dynamic – For show dynamic MAC Address
73. show epon active-onu mac-address d849.0b98.187d – For show onu number & uptime
74. show mac address-table brief – For know how many mac address in single onu
