EPON ONU SHOW COMMAND
#show epon active-onu – All Active ONU information
#show epon active-onu mac-address 8479.73fb.3f9d – Search onu by mac address
#show epon always-laser-on-onu – For check Always laser status on the ONU
#show epon always-laser-on-onu interface epON 0/1 – For Specific epon Always laser status on the ONU
#show epon inactive-onu -For show Inactive ONU information
#show epon inactive-onu interface epoN 0/1 – For Specific epon interface inactive ONU information
#show epon interface epON 0/1:6 onu ctc basic-info -For ONU basic information
#show epon interface epON 0/1:1 onu port 1 state – For onu lan port status check
#show epon interface epon 0/1:14 onu ctc dba – For Show the oNU queue the DBA set the config
#show running-config interface epON 0/1:4 – For show specific onu configuration
#show epon optical-transceiver-diagnosis interface epoN 0/1 – For see specific epon all onu optical power(dBm)
#show epon optical-transceiver-diagnosis interface epON 0/1:4 – For Show Specific ONU optical power(dBm)
#show gpon onu-optical-transceiver-diagnosis interface gpON 0/7 – For show all onu rx tx power “GPON only”
#show epon onu-ctc-optical-transceiver-diagnosis interface epoN 0/1 – For show all onu rx tx power
#show epon onu interface epon 0/x:x onu ctc optical-transiver- diagnosis – For show all onu rx tx power
#show epon interface epoN 0/1:2 onu ctc snmp-info – For show ONU SNMP information
#show epon interface epON 0/1:2 onu d-info – For show Double mac address information
#show epon interface epON 0/1:2 onu mac address-table – For Show ONU MAC address table
#show epon interface epon 0/1: 1 onu mac-aging-time -For show onu Mac aging time
#show epon interface epon 0/1: 1 onu olt-info -For show olt information
#show epon interface epon 0/1: 1 onu pon-port statistics – For Show ONU interface statistics
#show epon interface epon 0/1: 1 onu pon-port state – For Show ONU interface state
#show epon interface epoN 0/2:8 onu port 1 ctc auto-negotiation – For show ONU interface auto negotiation
#show epon interface epoN 0/2:8 onu port 1 ctc flow-control – For Show ONU interface flow control state
#show epon interface epon 0/1: 1 onu port 1-4 ctc mcst mc-vlan – For show onu Multicast
#show epon interface epoN 0/2:8 onu port 1 ctc mcst tag-stripe – For show onu strive vlan tag
#show epon interface epoN 0/2:8 onu port 1 ctc qos – For show ONU interface qos
#show epon interface epON 0/1:21 onu port 1 ctc ratelimit-ingress / egress- Show ONU interface bandwidth limitation
#show epon onu-authen-method – For need to see onu authentication method
#show epon onu-information – For see all onu information under every epon
#how mac address-table interface epoN 0/1:1 – For show specific onu interface mac table
#show onu-config-template – For show template-config
#show epon active-onu mac-address d849.0b98.187d – For show onu number & uptime
#show mac address-table brief – For know how many mac address in single onu
#show epon active-onu mac-address 8479.73fb.3f9d – Search onu by mac address
#show epon always-laser-on-onu – For check Always laser status on the ONU
#show epon always-laser-on-onu interface epON 0/1 – For Specific epon Always laser status on the ONU
#show epon inactive-onu -For show Inactive ONU information
#show epon inactive-onu interface epoN 0/1 – For Specific epon interface inactive ONU information
#show epon interface epON 0/1:6 onu ctc basic-info -For ONU basic information
#show epon interface epON 0/1:1 onu port 1 state – For onu lan port status check
#show epon interface epon 0/1:14 onu ctc dba – For Show the oNU queue the DBA set the config
#show running-config interface epON 0/1:4 – For show specific onu configuration
#show epon optical-transceiver-diagnosis interface epoN 0/1 – For see specific epon all onu optical power(dBm)
#show epon optical-transceiver-diagnosis interface epON 0/1:4 – For Show Specific ONU optical power(dBm)
#show gpon onu-optical-transceiver-diagnosis interface gpON 0/7 – For show all onu rx tx power “GPON only”
#show epon onu-ctc-optical-transceiver-diagnosis interface epoN 0/1 – For show all onu rx tx power
#show epon onu interface epon 0/x:x onu ctc optical-transiver- diagnosis – For show all onu rx tx power
#show epon interface epoN 0/1:2 onu ctc snmp-info – For show ONU SNMP information
#show epon interface epON 0/1:2 onu d-info – For show Double mac address information
#show epon interface epON 0/1:2 onu mac address-table – For Show ONU MAC address table
#show epon interface epon 0/1: 1 onu mac-aging-time -For show onu Mac aging time
#show epon interface epon 0/1: 1 onu olt-info -For show olt information
#show epon interface epon 0/1: 1 onu pon-port statistics – For Show ONU interface statistics
#show epon interface epon 0/1: 1 onu pon-port state – For Show ONU interface state
#show epon interface epoN 0/2:8 onu port 1 ctc auto-negotiation – For show ONU interface auto negotiation
#show epon interface epoN 0/2:8 onu port 1 ctc flow-control – For Show ONU interface flow control state
#show epon interface epon 0/1: 1 onu port 1-4 ctc mcst mc-vlan – For show onu Multicast
#show epon interface epoN 0/2:8 onu port 1 ctc mcst tag-stripe – For show onu strive vlan tag
#show epon interface epoN 0/2:8 onu port 1 ctc qos – For show ONU interface qos
#show epon interface epON 0/1:21 onu port 1 ctc ratelimit-ingress / egress- Show ONU interface bandwidth limitation
#show epon onu-authen-method – For need to see onu authentication method
#show epon onu-information – For see all onu information under every epon
#how mac address-table interface epoN 0/1:1 – For show specific onu interface mac table
#show onu-config-template – For show template-config
#show epon active-onu mac-address d849.0b98.187d – For show onu number & uptime
#show mac address-table brief – For know how many mac address in single onu
