Viewing information about
ONT (ONU) on EPON OLT BDCOM P3310C, on other models is essentially the same.
Connect to OLT and go
into configuration mode:
|
1 2 |
. enable . config |
To view
the ONU list, use the commands:
|
1 2 3 |
. show epon onu-information . show epon active-onu . show epon inactive-onu |
Example
of viewing MAC addresses on a port or ONU:
|
1 2 3 |
. show mac address-table
interface EPON0/1 . show mac address-table
interface EPON0/1:5 . show mac address-table brief |
View
the optical power that comes from the OLT to the ONU (ONU RX):
|
1 |
. show epon interface ePON
0/1:5 onu ctc optical-transceiver-diagnosis |
View
the optical power that comes from ONU to OLT (OLT RX):
|
1. |
show epon
optical-transceiver-diagnosis interface EPON 0/1 |
View
ONU models and firmware versions:
|
1 2 |
. show epon
onu-software-version . show epon
onu-software-version interface EPON 0/1 |
View
description and status of interfaces:
|
1. |
show interface brief |
ONU
ethernet port status and viewing statistics:
|
1 2 3 |
. show epon interface epON
0/1:1 onu port 1 state . show epon interface epON
0/1:1 onu port 1 statistics . show epon interface epON
0/1:1 onu mac address-table |
Also
you can see in the saved and active OLT configuration which ONUs are
registered:
|
1 2 |
show configuration show running-config |
ONU
reboot example:
|
1 |
. epon reboot onu interface
ePON 0/1:1 |
