1. Setup interface vlan-id
2. Setup ip addres
3. Assign vlan-id at interface
4.configure default gateway
5. show ip addres on vlan-id ***** show interface vlan-id **********
6. Configure Username Password Enable for console and Telnet****** aaa authenication login default login
aaa authenication enable default enable
username bdcom password bdcom
enable password bdcom
service password encription *********
7. Duplex Setting
PALTAN-BDCOM>ena
PALTAN-BDCOM#conf
PALTAN-BDCOM_config#interface gigaEthernet 0/1
PALTAN-BDCOM_config_g0/1#duplex ?
auto — Enable AUTO duplex configuration
full — Force full duplex operation
half — Force half-duplex operation
PALTAN-BDCOM_config_g0/1#duplex
8. Setting speed option
PALTAN-BDCOM#config
PALTAN-BDCOM_config#interface gigaEthernet 0/1
PALTAN-BDCOM_config_g0/1#speed ?
10 — Force 10 Mbps operation
100 — Force 100 Mbps operation
auto — Enable AUTO speed configuration
9. Showing speed and duplex
===============================
PALTAN-BDCOM#show interface gigaEthernet 0/1
GigaEthernet0/1 is down, line protocol is down
Ifindex is 1, unique port number is 1
Hardware is Giga-TX, address is 8479.737f.7ed4 (bia 8479.737f.7ed4)
MTU 1500 bytes, BW 1000000 kbit, DLY 10 usec
Encapsulation ARPA
Auto-duplex, Auto-speed, Flow-Control Off
5 minutes input rate 0 bits/sec, 0 packets/sec
5 minutes output rate 0 bits/sec, 0 packets/sec
Received 0 packets, 0 bytes
0 broadcasts, 0 multicasts
0 discard, 0 error, 0 PAUSE
0 align, 0 FCS, 0 symbol
0 jabber, 0 oversize, 0 undersize
0 carriersense, 0 collision, 0 fragment
0 L3 packets, 0 discards, 0 Header errors
Transmitted 0 packets, 0 bytes
0 broadcasts, 0 multicasts
0 discard, 0 error, 0 PAUSE
0 sqettest, 0 deferred, 0 oversize
0 single, 0 multiple, 0 excessive, 0 late
0 L3 forwards
10. Showing mac address table
=====================================
PALTAN-BDCOM#show mac address-table
Mac Address Table (Total 735)
——————————————
Vlan Mac Address Type Ports
—- ———– —- —–
520 0005.9b25.afd9 DYNAMIC tg0/4
1220 b869.f400.b7bf DYNAMIC g0/21
425 18d6.c794.5159 DYNAMIC tg0/3
425 18d6.c755.3543 DYNAMIC tg0/3
143 0005.9b25.afd9 DYNAMIC tg0/4
11. Saving Configure
===========================================
PALTAN-BDCOM#write
Saving current configuration…
OK!
12. Clearing NVRAM (Reset the system configuration to factory default
======================================
PALTAN-BDCOM#delete
————————————————
| Advanced Configure |
————————————————
#mac addres security
#VLAN & 802.1Q VLAN TRUNK
#Spanning Tree Configure (STP)
#CAR Configure
#System MTU Configure
#SNMP Configure
#LLDP Configure
#Port Aggregration
#802.3ah configuration
#Password Recovery
13. MAC Address security
================================
PALTAN-BDCOM_config#interface gigaEthernet 0/1
PALTAN-BDCOM_config_g0/1#switchport port-security mode st
static sticky
PALTAN-BDCOM_config_g0/1#switchport port-security mode static ?
accept — Accept mode
reject — Reject mode
14. Vlan configuration
=======================================
PALTAN-BDCOM#config
PALTAN-BDCOM_config#vlan 1000
PALTAN-BDCOM_config_vlan1000#name test
15. Assigning switch port to a vlan
==============================================
Madartek>ena
Madartek#config
Madartek_config#interface gigaEthernet 0/1
Madartek_config_g0/1#switchport pvid 413
16. Varifying a Vlan
============================================
Madartek#show vlan
17. Configure 802.1Q VLAN TRUNK
================================================
Madartek#config
Madartek_config#interface gigaEthernet 0/1
Madartek_config_g0/1#switchport mode trunk
18. Configure Spanning Tree Protocol
=================================================
Madartek>ena
Madartek#config
Madartek_config#spanning-tree mode rstp ?
Madartek_config#spanning-tree mode ?
mstp — Setup multiple spanning-tree protocol mode
pvst — Setup spanning-tree protocol pvst mode
rstp — Setup rapid spanning-tree protocol mode
sstp — Setup spanning-tree protocol sstp mode
Madartek_config#spanning-tree mode rstp
Madartek_config#spanning-tree rstp priority 32768
19. Varifying Spanning Tree
=====================================
Madartek#show spanning-tree
Spanning tree enabled protocol RSTP(2004)
RSTP
Root ID Priority 32768
Address 000A.5A41.FC4F
Port TGigaEthernet0/3
Cost 28004
Hello Time 2 sec Max Age 20 sec Forward Delay 15 sec
Bridge ID Priority 32768
Address 8479.737F.9337
Hello Time 2 sec Max Age 20 sec Forward Delay 15 sec
Interface Role Sts Cost Pri.Nbr Type
—————- —- — ——— ——– ———————–
g0/22 Desg FWD 20000 128.22 Edge
g0/23 Desg FWD 20000 128.23 Edge
tg0/2 Desg FWD 2000 128.26 P2p
tg0/3 Root FWD 2000 128.27 P2p
20. CAR( Commit Access Rate) Limit bandwidth of a switch port
===================================================================
Madartek#config
Madartek_config#interface gigaEthernet 0/1
Madartek_config_g0/1#switchport rate-limit ?
<1-16384> — Configure Bandwidth(unit:64kbps)
bandwidth — Configure Bandwidth(unit:1% of physical bandwidth)
Madartek_config_g0/1#switchport rate-limit 1 ?
ingress — Config port rate-limit ingress
egress — Config port rate-limit egress
Madartek_config_g0/1#switchport rate-limit 1 ingress
Madartek_config_g0/1#switchport rate-limit 1 egress
21. MTU ( Maxium Transfer Unit )
=====================================================
Madartek#config
Madartek_config#system mtu ?
<1500-9216> MTU size in bytes
22. Show MTU ( Maxium Transfer Unit )
==========================================
Madartek#show system mtu
System MTU size is 1500 bytes
23. SNMP ( Simple Network Management Protocol ) Public and Private
=====================================================================
Madartek#config
Madartek_config#snmp-server community public r
ro rw
Madartek_config#snmp-server community public r
ro rw
Madartek_config#snmp-server community public rw
24. LLDP ( Link Layer Discovery Protocol ) update information between two switch
================================================================================
Madartek#config
Madartek_config#lldp ?
holdtime — Specify the holdtime (in sec) to be sent in packets
reinit — Delay (in sec) for LLDP initialization on any interface
run — Enable PTOPO discovery protocol to run
timer — Specify the interval at which packets are sent
tlv-select — Selection of LLDP TLVs to send
trap-send — Send SNMP trap
25. Show LLDP ( Link Layer Discovery Protocol ) update information between two switch
================================================================================
PALTAN-BDCOM_config#show lldp neighbors
Madartek#show lldp neighbor detail
26. Port Aggregration
=================================
Madartek>ena
Madartek#config
Madartek_config#interface port-aggregator ?
<1-8> — Port-aggregator interface number
Madartek_config#interface gigaEthernet 0/1
Madartek_config_g0/1#aggregator-group ?
<1-8> — aggregator group number
27. Password Recovery
==========================================
#Go to monitor mode for check your username & password
#Reboot & Pressing ctrl+P make switches go to monitor mode
monitor#show configuration
28. Delete configuration & Reboot
=============================================
monitor#delete
monitor#reboot
29. Spanning Tree vlan priority
=================================================
PALTAN-BDCOM_config#spanning-tree vlan 115,215,315 priority 16
Bridge priority should be one of the following values:
0 4096 8192 12288 16384 20480 24576 28672
32768 36864 40960 45056 49152 53248 57344 61440
PALTAN-BDCOM_config#spanning-tree vlan 115,215,315 priority 4096
30. Spanning Tree port priority
=====================================================
Dolaikhali_config_g0/24#spanning-tree port-priority 230
Port priority should be one of the following values:
0 16 32 48 64 80 96 112
128 144 160 176 192 208 224 240
31. Show spanning tree specific internerface
========================================
PALTAN-BDCOM#sh spanning-tree ?
detail — Display spanning-tree detail information
interface — Display spanning-tree interface information
mstp — Display multiple spanning tree protocol information
pvst — Display spanning-tree pvst information
vlan — Display spanning-tree vlan information
PALTAN-BDCOM#sh spanning-tree interface gigaEthernet 0/24
32. Configure spanning tree path cost of vlan & interfaces
==========================================
PALTAN-BDCOM_config_g0/24#spanning-tree vlan 115,215,315 ?
cost — Setup spanning-tree protocol port cost
port-priority — Setup spanning-tree protocol port priority
PALTAN-BDCOM_config_g0/24#spanning-tree vlan 115,215,315 cost 10000
PALTAN-BDCOM_config_g0/24#spanning-tree rstp ?
cost — Setup spanning-tree protocol port cost
port-priority — Setup spanning-tree protocol port priority
edge — Configure edge port
point-to-point — Set the point-to-point link status
migration-check — Clear detected protocol information
PALTAN-BDCOM_config_g0/24#spanning-tree rstp cost 10000
PALTAN-BDCOM_config_g0/24#ex
PALTAN-BDCOM_config#wr
https://slideplayer.com/slide/6393664/
**********************************************
Remove Command
**********************************************
Delete ip address from interface
——————————————————
Config# int vlan 1
Config# no ip address
Delete username
——————————————————
Maghbazar_config#no username admin
VLAN CONFIGURATION
————————————————–
#For
interface GigaEthernet0/21
switchport trunk vlan-allowed 101,111,211,311,404
switchport trunk vlan-untagged 1
switchport pvid 407
2. PALTAN-BDCOM_config_g0/1#switchport mode trunk
3. PALTAN-BDCOM_config_g0/1#switchport mode access
